Horizontālie virpošanas centri

305 produkti

Horizontālās virpas – plaši izmantojams risinājums

Horizontālās virpas ir svarīga jebkuras ražošanas daļa. Šī ir visplašāk izmantotā tehnoloģija, kas nodrošina milzīgu elastību, jo ar to var apstrādāt praktiski jebkura izmēra detaļas, sākot no 1/10 milimetra līdz aptuveni 4 metru diametra lielām detaļām. Apstrādājot garas detaļas, jūs varat atbalstīt tās ar stabilu balstu tuvu griezējlīnijai, nodrošinot augstu precizitātes pakāpi.

Turklāt horizontālās virpas piedāvā plašas izmantošanas iespējas. Tieši tāpēc tās būs lielisks ieguldījums: papildu priekšrocībām, kas saistītas ar atrašanās vietu, horizontālās virpas ļauj apstrādāt detaļas no visdažādākajiem materiāliem, piemēram, metāla, plastmasas un koka.

Horizontālās virpas piedāvā plašas automatizācijas un bezapkalpes darbības iespējas. Piemēram, tajās var izmantot stieņu iekrāvēja magazīnu, kas virpai piegādā detaļas. Stieņu iekrāvēja magazīnas izmēri variē no Ø5 līdz Ø100, un garums – no 1 līdz 6 metriem.

Dažādie vārpstas apgriezienu ātrumi un griezes momenta iespējas ļauj apstrādāt dažādus materiālus – no alumīnija līdz titānam.

Lietotājam draudzīga vadība

Modernās CNC vadības ierīces ir ērti lietojamas un ļauj viegli ieprogrammēt virpu, palielinot produktivitāti. Iegādājoties Duroc Machine Tool iekārtu DN Solutions, parasti jūs varat izvēlēties vienu no trīs vadības sistēmām – FANUC, Siemens un Mitsubishi.

Kārtot pēc

General

Control System

Sērija

Travels

Main spindle

Capacity

LYNX 2100A
LYNX 2100A

LYNX 2100A

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 330
LYNX 2100A
LYNX 2100A

LYNX 2100A

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 330
LYNX 2100B
LYNX 2100B

LYNX 2100B

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 330
LYNX 2100B
LYNX 2100B

LYNX 2100B

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 330
LYNX 2100B-NT
LYNX 2100B-NT

LYNX 2100B-NT

LYNX 2100LA
LYNX 2100LA

LYNX 2100LA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 550
LYNX 2100LA
LYNX 2100LA

LYNX 2100LA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 550
LYNX 2100LB
LYNX 2100LB

LYNX 2100LB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 550
LYNX 2100LB
LYNX 2100LB

LYNX 2100LB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 550
LYNX 2100LC
LYNX 2100LC

LYNX 2100LC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 537
LYNX 2100LC
LYNX 2100LC

LYNX 2100LC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 350
  • Max. Turning Length (mm): 537
LYNX 2100LMA
LYNX 2100LMA

LYNX 2100LMA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMA
LYNX 2100LMA

LYNX 2100LMA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 340
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMB
LYNX 2100LMB

LYNX 2100LMB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMB
LYNX 2100LMB

LYNX 2100LMB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMC
LYNX 2100LMC

LYNX 2100LMC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 497
LYNX 2100LMC
LYNX 2100LMC

LYNX 2100LMC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 497
LYNX 2100LMSA
LYNX 2100LMSA

LYNX 2100LMSA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMSA
LYNX 2100LMSA

LYNX 2100LMSA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMSB
LYNX 2100LMSB

LYNX 2100LMSB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMSB
LYNX 2100LMSB

LYNX 2100LMSB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LMSC
LYNX 2100LMSC

LYNX 2100LMSC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 487
LYNX 2100LMSC
LYNX 2100LMSC

LYNX 2100LMSC

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 254
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 487
LYNX 2100LSYA
LYNX 2100LSYA

LYNX 2100LSYA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LSYA
LYNX 2100LSYA

LYNX 2100LSYA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LSYB
LYNX 2100LSYB

LYNX 2100LSYB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LSYB
LYNX 2100LSYB

LYNX 2100LSYB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LYA
LYNX 2100LYA

LYNX 2100LYA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LYA
LYNX 2100LYA

LYNX 2100LYA

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Y Axis Travel distance (mm): 105
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 152.4
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
LYNX 2100LYB
LYNX 2100LYB

LYNX 2100LYB

  • Travels - X Axis Travel distance (mm): 205
  • Travels - Z Axis Travel distance (mm): 560
  • Chuck size (mm): 203.2
  • Max. Turning Diameter (mm): 300
  • Max. Turning Length (mm): 510
30 no 305 produkti
